860-960Mhz UHF RFID Reader with RS232/WG26/34/RS485 Interface

Introduction

Integrated, high performance 12dBi vertical antenna ensure long-range reading& writing and easy installation;

Multi-protocol support: ISO 18000-6B&ISO 18000-6C(EPC Gen2);

Super anti-interference ability for its FHSS frequency working method;

Software with different Programming language allows easy upgrade;

Waterproof and sunshine defending, idea for outdoor applications;

All kinds of communication interfaces and customizing is available too.



Frequency range: 902MHz~928MHz or 865MHz~868MHz
Protocol: ISO18000 6C Gen 2
Operating method: FHSS or fixed frequency
Antenna: 12dBi polarization
Power smothness: <0.5DB
RF power range: 0~30dBm (adjust by software)
Development kit: C, C++, C#, JAVA SDK
Identify tag time: <10ms (single tag)
Reading distance: 3-6m
Communication interface: Wiegand, RS232, RS485 (TCP/IP , WIFI customized)
Input/output: 1 road trigger input and 1 road relay output
Power supply: DC7.5V-12V , 3A
Antenna power: 1W
Dimension: 450*450*50mm
Weight: 9kgs
Working temperature: -45℃ to 65℃
Storage temperature: -30℃ to 75℃



Application

Intelligent traffic such as ETC;

Custom border-crossing;

Parking lot;

Automatic weighting;

Logistics such as container management;

Pallet management;

Asset tracing etc.;

Ticketing and access control system.
