1. Introduction
This is a low frequency tag scanner that using wireless identification technology and it
suppors reading EMID, FDX-B(ISO11784/85) etc. tag.
This scanner using high brightness OLED display screen, and can be seen clearly inside
the house or under the strong light outside. It can store up to 6000 tag information with its
built-in memory, users can send the information to the computer through USB cable or
wireless connection to manage data.
This product is stable and easy to use, it can be used for animal management, resource
management, railway inspection etc..
2. Performance parameter
| Frequency | 134.2Khz/125Khz |
| Tag format | EMID、FDX-B(ISO11784/85) |
| Reading/writing disatnce | 2*12mm glass tag>15cm;30mm animal tag>25cm |
| Reading access time | <100ms |
| Signal indicator | 128*64 high brightness OLED、buzzer |
| Power | 3.7V-4.2V(Li battery) |
| Power consumption | Working:0.9W ；Standby:0.04W |
| Storage capacity | 6000 information(tag coding+time) |
| Storage time | >20 years |
| communication port | USB2.0,wireless USB HID(optional), Bluetooth(optional) |
| Weight | 300g (without battery) |
| Languaege | Chinese,English(Can be customized to your requirement) |
| Work temperature | -10℃～50℃ |
| Storage temperature | -30℃～70℃ |
| Software | Supply it for free |
